Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machinery. They produce machinery like boom lifts, aerial lifts and manlifts. These types of machinery are designed to facilitate access to hard to reach areas, roofs and buildings, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt only moves in one direction and includes platforms, or steps or handholds which are attached to the unit in order to move personnel from every floor.
TB85
The TB85 by Terex offers a maximum working height of 91 feet. In addition, the platform's maximum height reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model offers a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is approximately 8.5 feet wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height measures at 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 provides a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
